VISIOMODBalkongräcken i aluminium
EasyMod MARS-H Horisontell Stång
EM-MHMARS-H — Horizontal Rail, Aluminium or Stainless Steel
EasyMod MARS-H is the horizontal rail variant of the MARS system, available in two material specifications: powder-coated aluminium (EN AW-6063 T6, any RAL colour) and 316L stainless steel (brushed or mirror polished). Both share the same post geometry and fixing system, allowing mixed-material specifications across a single building. Horizontal bar profiles available: **Ø12mm round** (slender, refined — most popular for residential), **Ø16mm round** (slightly heavier presence), **14×14mm square** (architectural, precise shadow lines), **30×15mm flat** (linear blade, medium visual weight), **50×15mm flat** (wide blade, strong privacy — reads as a louvre panel from street level). Bar spacing is 100–120mm horizontally within the panel. The horizontal orientation creates a clean linear rhythm and is wind-permeable — reducing wind pressure on exposed balcony faces and making the system well-suited for high-rise facades and coastal settings. Both aluminium and stainless versions comply with EN 1991-1-1 residential and commercial load requirements.
VIKTIGA EGENSKAPER
- Aluminium or 316L stainless steel
- 5 bar profiles: Ø12 / Ø16 / 14×14 / 30×15 / 50×15mm
- 50–80% adjustable privacy
- Wind-permeable — less drag on facades
- Any RAL powder coat (alu) or brushed/mirror (SS)
- Floor-mount, side-mount or face-fix
- EN 1991-1-1 residential & commercial
TEKNIK & DETALJERKonstruktion som presterar.
5 Bar Profile Options
Ø12mm round · Ø16mm round · 14×14mm sq · 30×15mm flat · 50×15mm flat — same post, different visual weight. Mix profiles across floors.
50×15mm Wide Blade
The widest flat bar creates louvre-like horizontal bands — strong shadow lines and ~65% opacity from street level. Popular for facade privacy screening.
Aluminium — Any RAL Colour
TIGER Drylac powder coat QUALICOAT Class II on EN AW-6063 T6 profiles. Match any facade colour exactly. UV stable, 20+ year outdoor durability.
316L Stainless Steel
Marine-grade 1.4404 stainless — brushed K320 satin or mirror polished. No painting required, no rust, ideal for coastal and urban environments.
Wind-Permeable Design
Horizontal bars allow air to pass through, reducing wind load on the railing and creating a more comfortable balcony environment in exposed locations.
Mixed Material on One Building
Aluminium and stainless versions share the same post and fixing details — different floors or zones can use different materials without changing the structural layout.
Technical DetailsEasyMod MARS-H.
Modular Aluminium Railing System
Load Scenarios
EN 1991-1-1 Residential / 1.5 kN/m Commercial
Height & Infill
TEKNISKA SPECIFIKATIONERByggt enligt standard.
ANVÄNDNINGSOMRÅDENDär det fungerar.
The Mars-H horizontal rail is ideal for residential balconies on mid-rise and high-rise apartment buildings, terraces exposed to wind, and facades where a contemporary…
VANLIGA FRÅGORVanliga frågor.
Five sections: Ø12mm round (slender, most popular), Ø16mm round, 14×14mm square, 30×15mm flat, 50×15mm flat (widest — creates louvre-like privacy from street level). All profiles available in both aluminium and 316L stainless steel.
Aluminium is lighter, available in any RAL colour, and lower cost. It is the default choice for residential developments with a specific facade colour scheme. Stainless steel is maintenance-free, requires no paint, and delivers a premium metallic appearance — preferred for commercial projects, coastal settings, and developments where the railing finish needs to remain consistent over 20+ years without repainting.
Yes. Both use identical post dimensions and fixing plates. A common approach is stainless for ground-floor commercial frontages (higher abuse and visibility) and aluminium for upper residential floors.
316L (1.4404) is marine-grade stainless — the standard for coastal and offshore applications. It will not rust or pit in normal salt-air environments. Regular washing (twice yearly) removes salt deposits and maintains appearance.
100mm horizontal bar spacing is standard for fall protection. 120mm is acceptable under DIN 18065 for certain configurations. Tighter spacing increases privacy but reduces wind permeability.
FÄRGER & YTBEHANDLINGARDin färg, din stil.
Aluminium: any RAL Classic or RAL Design colour, smooth or textured, QUALICOAT Class II. Wood-effect sublimation print available. Stainless steel: K320 brushed satin…
SKÖTSEL & UNDERHÅLLByggt för att förbli vackert.
Aluminium: wipe down 2–3 times per year with mild detergent. No painting required for 20+ years. Stainless steel: wash with water and mild soap twice per year to…
