EN 13501 fire class for outdoor structures — when A1 / A2 / B is mandated.

Fire class on the spec sheet rarely ends a discussion — it starts one. This guide explains what EN 13501-1 measures, why an aluminium pergola lands at A1 without effort, and the scenarios where a hotel, restaurant or public-venue brief escalates the requirement and what changes structurally.

What EN 13501-1 actually classifies

EN 13501-1 — *Fire classification of construction products and building elements* — assigns every construction material a single-letter Euroclass plus two suffixes:

- A1, A2 — non-combustible. A1 contributes nothing to a fire; A2 has a tiny, measurable contribution. - B, C, D — combustible, with B making the smallest contribution and D the largest. - E, F — easily ignitable. F = "no performance determined". - Suffix s1 / s2 / s3 — smoke production (s1 = least smoke). - Suffix d0 / d1 / d2 — flaming droplets (d0 = none, d2 = significant).

A typical full classification reads "A2-s1, d0" — non-combustible, low smoke, no droplets.

The standard's test methods are SBI (Single Burning Item, EN 13823) for B–D and the non-combustibility / calorimetric tests (EN ISO 1182, EN ISO 1716) for A1 / A2.

Why aluminium pergolas hit A1 by default

Pure structural aluminium (the EN AW 6063-T5 / 6060-T66 alloys we use for posts, beams and louvres) is non-combustible and tests at A1 under EN 13501-1 with no special treatment. Same for the steel anchors, stainless fasteners and toughened glass infills. Powder coating adds a 60–80 µm organic layer, but the layer is too thin to shift the substrate's classification — coated aluminium remains A1.

This means the typical Luxa Sereno pergola, the Aperio retractable louvre roof and the VisioMod fence + glass railing all carry an A1 classification on the structural body without specifier action.

When the suffix or the body class actually matters

Three components in an outdoor structure can drag the system below A1:

1. PVB interlayer in laminated glass — VSG per EN 14449 has a 0.76–1.52 mm PVB sandwich. The interlayer is plastic and burns. The composite glass sheet is typically B-s1, d0 (the PVB is so thin it gives off little smoke and no droplets). 2. PVC mesh in zip screens — Velario / Tela 100 family fabric is PVC-coated polyester. Typical classification B-s2, d0 to C-s2, d0 depending on the fire-retardant treatment. 3. WPC slats in privacy fences — Wood-plastic composite slats (Bosco / Verto WPC variant) test in the C-s2, d0 to D-s2, d0 band.

For a normal residential project, none of this matters. Building regulations cover the building, not the freestanding outdoor structure. Where it does matter:

Four hospitality / public-assembly scenarios

1. Restaurant / hotel terrace canopy used for indoor-feeling dining. When the canopy roof + side walls together enclose the dining area to the point where the building authority treats it as a *Versammlungsstätte* (assembly venue) under DE Bauordnung MVStättVO or its national equivalent, the canopy assembly must hit A2-s1, d0 or better. Aluminium frame keeps the body A1; the laminated-glass infill needs an A2-rated alternative or the brief picks toughened single-pane ESG (no PVB) instead. 2. Outdoor cooking / open flame near pergola posts. Wood-fired pizza ovens, charcoal grills and gas patio heaters under the canopy — the EN 1991-1-2 (Eurocode 1 fire actions) annex requires the canopy frame to remain non-combustible within a hot-zone radius. Aluminium passes; WPC infill panels move out of that zone or get replaced with aluminium slats. 3. Hospital / care-home outdoor patient areas. Public hospital procurement in DE / AT / CH defaults to A2-s1, d0 for any structure within an evacuation-route footprint. The architect specifies aluminium frame + ESG glass infill (no laminate) to stay within class. 4. Public-procurement covered walkway / canopy over a pedestrian route. Covered walkways at schools, transport hubs, public squares — same A2-s1, d0 default. The fire-engineer brief explicitly excludes WPC and PVB-laminated glass; only aluminium + ESG glass + steel cable infills qualify.

Concrete spec deltas A1 vs B

For the manufacturer:

| Component | Default class | Hospitality / A2 spec | |---|---|---| | Frame (aluminium, posts + beams + louvres) | A1 | A1 (no change) | | Toughened glass infill (EN 12150, no PVB) | A1 | A1 (no change) | | Laminated glass (EN 14449, PVB) | B-s1, d0 | replace with EN 12150 ESG or laminated A2-rated interlayer | | WPC infill | C-s2, d0 to D-s2, d0 | replace with aluminium slat (Lineo / Sereno aluminium variant) | | PVC mesh fabric (zip screen) | B–C s2, d0 | omit, or replace with FR-rated solar mesh (EN 13501 B-s1, d0 grade) | | Powder coating | (substrate-dominated) | (substrate-dominated) |

Cost / lead-time impact:

- Switching laminated glass → toughened glass: −10 to −15 % glass cost, no lead-time penalty. - Switching WPC → aluminium slats: +10 to +20 % infill cost, no lead-time penalty. - FR-rated zip-screen fabric (when the brief allows): +15 to +25 % vs standard fabric. - Documentation pack (fire-test reports per component): supplied per project, no surcharge.

What to write in the tender

Three lines for an A2-mandated specifier brief:

1. Class target: "All structural elements of the canopy / fence shall achieve EN 13501-1 class A2-s1, d0 or better. Combustible-class infills (PVB-laminated glass, WPC, PVC mesh) are excluded." 2. Test reports: "Manufacturer ships the EN 13501-1 classification report per component (frame, infill, coating) with each delivery. Reports must be issued by an EN ISO 17025-accredited fire test laboratory." 3. Fall-back clause: "Where the building authority's fire-engineering review escalates the class above the supplied spec, the supplier will substitute infill components at no additional cost up to the next class."

For residential and standard commercial projects, no fire-class clause is required — the aluminium body's default A1 covers the brief.

Linking back to our products + tools

The PONARC group ships every load-bearing aluminium structure with the EN 13501-1 classification report on request — A1 on the frame, glass and louvres; A2-rated infill alternatives are quoted line-item where required. The full set of regulatory references (EN 13501 fire class, EN 1991-1-2 fire actions, EN 1090 execution class, planning permission per country) lives in the planning section of the standards hub.

For wind + snow load context that frequently lines up with hospitality fire-class projects (canopy structures often span both criteria), use the wind & snow specifier calculator.

---

*Need EN 13501-1 fire-class reports for a tender? Contact our engineering team — we ship the per-component classification pack within two working days.*
