PRODUCT DATASHEET
Visio AR-S Horizontal Rail
PRODUCT DATASHEET
Visio AR-S Horizontal Rail
EasyMod MARS-H — horizontal rail infill for the MARS (Modular Aluminium Railing System).
Key features
- Aluminium or 316L stainless steel
- 5 bar profiles: Ø12 / Ø16 / 14×14 / 30×15 / 50×15mm
- 50–80% adjustable privacy
- Wind-permeable — less drag on facades
- Any RAL powder coat (alu) or brushed/mirror (SS)
- Floor-mount, side-mount or face-fix
- EN 1991-1-1 residential & commercial
Technical specifications
| Bar Profiles | Ø12mm round · Ø16mm round · 14×14mm sq · 30×15mm flat · 50×15mm flat |
| Bar Spacing | 100–120 mm (horizontal) |
| Rail Spacing | 150–200 mm vertical (adjustable) |
| Post Section | 50×50mm sq. or Ø50mm rd. |
| Heights | 900 / 1000 / 1100 mm |
| Material — Aluminium | EN AW-6063 T6, TIGER Drylac QUALICOAT II, any RAL |
| Material — Stainless | 316L (1.4404), brushed or mirror polished |
| Mounting | Floor-mount (slab bolt), side-mount (slab edge), face-fix (wall) |
| Load | 1.0 kN/m residential; 1.5 kN/m reinforced commercial |
| Standard | EN 1991-1-1 / DIN 18065 |
Standards & certifications
- DIN 18065 · Stairs and railings (residential)
- EN 1991-1-1 · Densities, self-weight, imposed loads
- EN 1991-1-4 · Wind actions
- TRAV · Impact-resistant glazing (where applicable)
- EN 1090-3 · Execution of aluminium structures
- EN 12150 · Tempered safety glass
- EN AW-6063-T5 · Aluminium alloy / temper
- ISO 9001 · Manufacturer quality management
Warranty
10 years on aluminium frame · 5 years on TIGER powder coat · 5 years on motorised drive (where fitted). Conditions: install within 12 months of delivery, follow installation manual, observe rated wind/snow loads.
Order & support
PONARC Group · Sales: info@luxashade.com · Specifiers / architects: support@ponarc.com · Available across DE / AT / CH / NL / BE / FR / IT / RO / RU / SE / DK.
