PRODUCT DATASHEET
Visio Soglia Lift Glass Systems
PRODUCT DATASHEET
Visio Soglia Lift Glass Systems
Motorised vertically sliding glass wall — panels rise and disappear into ceiling cavity.
Key features
- Vertical sliding
- Motorised
- Ceiling-recessed
- Silent motor
- Max 3000mm height
Technical specifications
| Glass | 8 / 10 mm tempered (ESG) |
| Max Panel Height | 3000 mm |
| Max Panel Width | 1200 mm (single) / 3600 mm (multi) |
| Ceiling Cavity | Min. 150 mm deep |
| Motor | Silent electric, remote or wall switch |
| Multi-Panel | Up to 3 panels side-by-side |
| Header Profile | 150 mm deep aluminium |
| Surface Finish | Any RAL colour (TIGER Coatings) |
Standards & certifications
- DIN 18065 · Stairs and railings (residential)
- EN 1991-1-1 · Densities, self-weight, imposed loads
- EN 1991-1-4 · Wind actions
- TRAV · Impact-resistant glazing (where applicable)
- EN 1090-3 · Execution of aluminium structures
- EN 12150 · Tempered safety glass
- EN AW-6063-T5 · Aluminium alloy / temper
- ISO 9001 · Manufacturer quality management
Warranty
10 years on aluminium frame · 5 years on TIGER powder coat · 5 years on motorised drive (where fitted). Conditions: install within 12 months of delivery, follow installation manual, observe rated wind/snow loads.
Order & support
PONARC Group · Sales: info@luxashade.com · Specifiers / architects: support@ponarc.com · Available across DE / AT / CH / NL / BE / FR / IT / RO / RU / SE / DK.
