PRODUCT DATASHEET
Luxa Tela 100T — Horizontal Top Screen
PRODUCT DATASHEET
Luxa Tela 100T — Horizontal Top Screen
Horizontal zip screen mounted on pergola or veranda roofs.
Key features
- Top-mount installation
- Pergola/veranda integration
- Motorized operation
- UV protection 97%
- Multiple fabric options
Technical specifications
| Cassette | 100 × 120 mm aluminium |
| Max Width | 4000 mm |
| Max Projection | 5000 mm |
| Operation | Motorised (whisper-quiet) |
| Fabric | PVC or acrylic screen fabric |
| Wind review | Project wind route by fabric, size and exposure |
| Mounting | Pergola/veranda roof underside |
| Surface Finish | Any RAL colour (TIGER Coatings) |
Standards & certifications
- EN 1991-1-1 · Densities, self-weight, imposed loads
- EN 1991-1-3 · Snow loads
- EN 1991-1-4 · Wind actions
- EN 1090-3 · Execution of aluminium structures
- EN 12020-2 · Aluminium extrusion tolerances
- Qualicoat Class 2 · TIGER Coatings powder coat
- EN AW-6063-T5 · Aluminium alloy / temper
- ISO 9001 · Manufacturer quality management
Warranty
10 years on aluminium frame · 5 years on TIGER powder coat · 5 years on motorised drive (where fitted). Conditions: install within 12 months of delivery, follow installation manual, observe rated wind/snow loads.
Order & support
PONARC Group · Sales: info@luxashade.com · Specifiers / architects: support@ponarc.com · Available across DE / AT / CH / NL / BE / FR / IT / RO / RU / SE / DK.
