PONARC × LUXASHADE
FRAME · STEP D6 · 06 OF 8
06

Mount the right short beam

Right short beam closes the rectangle — measure both diagonals now.

Mount the right short beam — illustration
Fig. 06 — Mount the right short beam

SUB-STEPS

  1. 1Position the right short beam into the open side of the frame.
  2. 2Align both end joints with the carrier beams.
  3. 3Insert fixing set and clamp lightly.
  4. 4Measure two diagonals to confirm squareness.
  5. 5Tighten the right side fasteners.
  6. 6Confirm the frame is ready for lamel rails.

SPECIFICATIONS

  • Short beam / gutter profile: PN-GP-100
  • Diagonal tolerance: ±3 mm
  • Side fasteners: M8 fixing set
  • Frame status: fully closed rectangle
  • Install team: 2 installers

TIP

Measure both diagonals after the right side closes the frame.

WATCH OUT

A twisted frame will bind the lamels during rotation.

TOOLS

Tape measure, square, clamp, torque wrench

TIME

12 min

About step 6 of the Luxa Sereno 700 installation

Mount the right short beam · FRAME · 8 step · Luxa Sereno 700 (bioclimatic pergola)

Right short beam closes the rectangle — measure both diagonals now.
